Socionext Announces Shipment Of The World’s First HD-PLC LSI Compliant With IEEE 1901-2020

  • このエントリーをはてなブックマークに追加
Socionext Announces Shipment Of The World’s First HD-PLC LSI Compliant With IEEE 1901-2020

State-Of-The-Art, Compact, Low Power Device Supports Existing And New IoT Communication Applications



Yokohama, May 31, 2022— Socionext Inc. today announced sample shipments of the SC1320A HD-PLC communication LSI starting in June 2022 and plans to start volume production in the third quarter of 2022. This LSI is the world’s first semiconductor design using an IEEE 1901-2020 compliant IP core licensed by Panasonic Holdings Corporation.
Socionext will present the SC1320A LSI and evaluation kit at the HD-PLC Alliance booth at the JECA Fair 2022 held at Tokyo Big Sight from June 1 – 3, 2022.
“SC1320A” Product Information: https://www.socionext.com/en/products/assp/HD-PLC

HD-PLC Conforms to Standard IEEE 1901 -2020
The High-Definition Power Line Communication (HD-PLC) is a wired communication technology that supports communication networks by superimposing high-frequency signals (2 ~ 28 MHz) over existing power lines, telephone lines, twisted-pair, coaxial cables, and other wire types. In 2021, the 4th generation of HD-PLC was published in the IEEE 1901 -2020 standard specifies 1/2 and 1/4 transmission modes to enable longer distance communications. It is capable of facilitating a communication or network up to a reach of 10 km when combined with multi-hop technology. With these new features, this advanced HD-PLC solution is expected to become more widely adopted in many different fields and new application areas.

SC1320A Features and Specifications
The SC1320A is the world’s first LSI that adopts the 4th generation HD-PLC (*1) with an IP core that conforms to the IEEE 1901-2020 standard licensed by Panasonic Holdings Corporation.
Socionext’s strength in advanced signal processing analog frontend and circuit design technology enables implementation of the HD-PLC4 specification and features on the SC1320A while maintaining very low power consumption (200 mW). It uses only a single 3.3V power supply and comes in a compact 7 x 7 mm package. This solution has built-in I/Os such as SPI/UART and Ethernet MAC (RMII), allowing SC1320A to be easily embedded into home appliances, HEMS, and IoT products.

Future Development
Socionext has developed a radar sensor*2 with a built-in high-level detection of a person’s position and movement, and SC1330A*3,a LPWAN 2.0 compatible, low-power and low-cost LSI for IoT tags. Socionext believes the combination of these solutions with the SC1320A LSI can deliver more value to IoT and Smart Connected Systems and Devices. For example, a highsensitivity presence detection radar sensor can be used in a comprehensive hybrid communication network incorporating both the SC1320A and the SC1330A.
The small sized, low power SC1320A HD-PLC LSI helps companies develop high-end product at a lower cost. Socionext will continue to leverage the 4th generation HD-PLC benefits and features to create new technologies, values, and contribute to the future of Society 5.0.

Contact information for purchasing products and samples
Contact Form: https://www.socionext.com/en/contact/
